The main equipment includes laser LASERLINE LDF 5000-60, laser head SCANSonIC ALO1, KUKA robot, production rhythm 15JPH, is currently in mass production stage.

Chongqing, the main line (including the top of the laser brazing) and Daye Zhongtai main line (including the top of the laser brazing) project, the laser are using IPG YLS-4000, laser head were used SCANSONIC brand ALO1 and ALO3, robot brands were KUKA And ABB. Both laser stations are used while the robot is usedLaser brazingTwo welds, while the robot to take the top cover fixture (4 cover fixture switch), the production of 24JPH beat, the current two projects were in production and small batch production stage.

Product application areas: automotive white body welding field

SAIC-PTZ SK81 / 91 vehicle roof laser brazing project, the main equipment, including laser IPG YLS-4000, laser head SCANSONICALO3, FAUNC robot, the workstationrobotFor the top cover on each side, each side has a robot for laser brazing, another robot for the top fixture to take action, the production of the beat 30JPH, welding station after the automatic grinding station, the current project in production stage.

 Product application areas: automotive white body welding field

Fujian Benz VS20 door laser flight welding production line project, the main equipment including laser Trumpf TruDisk4002, laser head PFO3D-2,KUKA robotAnd RPFO control system, a robot and a laser corresponding to the three turntable, welding process, including four doors inside the dimpling bumps and four doors inside and outside the boardLaser flight welding, Production rhythm 12JPH, is currently in mass production stage.

Product application areas: automotive white body welding field

Well - known electric car company battery shell cover laser brazing


Well - known electric car company batteryTop cover laser brazingProduction line project, the main equipment, including laser IPG YLS-4000, laser head SCANSonIC ALO3, FAUNC robot, beat a period of 88s, two 44s, is currently in small batch stage.

Product application areas: automotive power battery field

The main equipment includes laser IPG YLS-4000, laser head HIGHYAG BIMO, FAUNC robot, beat a 12JPH, two 20JPH, is currently in small batch stage.

Product application areas: automotive white body welding field
